Buick ENVISION 2023 - Front Turn Signal and Fog Lamps

Buick Envision Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16060855) - 2023 - CRC - 2/9/22
274 Vehicle Care
Fuses Usage
F82 ECM BATT – Engine
Control Module Battery
F83 ECM/IGN COIL – Engine
Control Module/Ignition
Coils
F84 MISC 1 – Mass Airflow/
Oxygen/Inlet Air
Temperature/Throttle
Inlet Absolute Pressure
and Humidity/Oxygen
Heated Sensor/Block
Coolant Valve/Evaporative
Emission Purge Pump/
Wide Range Air Fuel
Oxygen Sensor/Canister
Purge, Turbo Bypass,
Step Cam Intake,
Step Cam Exhaust, Engine
Oil Control Solenoids
F86 –
F87 S/ROOF – Sunroof
F88 AERO SH – Aeroshutter
F89 –
F93 TRLR PRK LAMP – Trailer
Park Lamp
Fuses Usage
F95 –
F96 –
F99 –
Relays Usage
K4 REAR DEFOG – Rear
Window Defog
K25 FRT/WPR/CNTRL – Front
Wiper Control
K37 FRT/WPR/SPD – Front
Wiper Speed
K64 STRTR MTR – Starter
Motor
K66 PWR/TRN – Power Train
K71 –
K73 A/C Control – Air
Conditioning Control
K80 STRTR PINION – Starter
Pinion
K90 –
K98 –
Instrument Panel Fuse Block
The instrument panel fuse block is on the
driver side of the instrument panel, between
the steering wheel and the door. To access
the fuses, remove the panel, starting at the
top. Once clips are disengaged, the tabs
along the bottom of the door can be
disengaged from the instrument panel to
remove the door.
To reinstall the door, place the bottom tabs
into the slots, and rotate the door into
position, engaging the clips. The vehicle may
not be equipped with all of the fuses, relays,
and features shown.
