ITEM PART NO. QTY. DESCRIPTION
15
ELECTRICAL AND OPERATING CONTROLS
1 03355.1000 1 Timer, Delay/Dilution - 100V & 120V
03355.1011 1 Timer, Delay/Dilution - 240V
03355.1003 1 Timer, Delay/Dilution - 120V w/Half Batch
01347.0000 2 Screw, Truss Head Serrated #6-32 x .375”
01388.0000 2 Screw, Pan Head #6-32 x .75”
01510.0000 2 Lockwasher, External Tooth #6
2 01533.0000 4 Spacer, .171” I.D. x .375” O.D. x .375” LG
3 03024.0005 1 Thermostat Kit 120V (Includes item 4)
01347.0000 1 Screw, Truss Head Serrated #6-32 x .375”
01510.0000 1 Lockwasher, External Tooth #6
20762.0000 2 Screw, Binding Head #8-32 x .25 (Terminal)
10003.0000 1 Tag, Thermostat
4 00720.0000 1 Knob, Thermostat
5 32400.0002 1 Digital Timer, Brew - 100V & 120V
32400.0003 1 Digital Timer, Brew - 230V
01388.0000 2 Screw, Pan Head #6-32 x .75”
01510.0000 2 Lockwasher, External Tooth #6
6 37080.0000 1 Switch, ON/OFF (Black) - 100V & 120V
03356.0003 1 Switch, UNSWEET/OFF/SWEET (Black)(Models with Sweetner Kit)
28305.0000 1 Switch, ON/OFF (Black) - 230V
7 37079.0000 1 Switch, Start (Black) - 100V & 120V
28303.0000 1 Switch, Start (Black) - 230V
8 00603.0000 1 Clamp, Cable
9 01309.0000 1 Screw, Power Cord Ground - Pan Head W/Washer #10-32 x .50” (Early models)
37804.0000 1 Screw, Power Cord Ground - Pan Head W/Washer #8-32 x .50” (Late models)
10 01685.0000 1 Cable Connector
11 12984.0002 1 Ready Light (Models with Ready Light)
12 00824.0000* 2 Decal, Ground
13 27705.0000 1 Terminal Lug
02308.0000 4 Screw, Pan Head #8-32 x .38”
Items lited below are not illustrated
14 21000.0725 1 Lead, Warmer Blanket to Main Harness 18AWG BLK 12.0” LG
21001.0723 1 Lead, Warmer Blanket to Main Harness 18AWG WHI 12.0” LG
15 01637.0006 1 Cord, Power 120V & 100V
27728.0001 1 Cord, Power 230V
16 03739.0000 1 Wiring Harness, Main 120V & 100V
03740.0001 1 Wiring Harness, Main 230V
17 00617.0000 - Tie, Cable 3.9” LG
18 21016.9004 1 Lead 16AWG BLU/BLK 16.0” LG
37237 071706
