Bunn TB3Q Illustrated Parts Catalog

ITEM PART NO. QTY. DESCRIPTION
15
* Indicates the part number listed is for reference only. See DESCRIPTION for possible service replacement.
ELECTRICAL AND OPERATING CONTROLS
1 00720.0000 1 Knob, Thermostat
2 03024.0005 1 Thermostat Assy, 206F Max (Includes Item 3)
01347.0000 2 Screw, Truss Head #6-32 x .38”
01510.0000 2 Lockwasher, External Tooth #6
20762.0000 2 Screw, Binding Head #8-32 x .25” (Terminal)
10003.0000 1 Tag, Thermostat
3 37080.0000 1 Switch, ON/OFF - 120V
03356.0003 1 Switch, UNSWEET/OFF/SWEET (Models with Sweetner Kit)
28305.0000 1 Switch, ON/OFF - 230V
4 37079.0000 1 Switch, START - 120V
28303.0000 1 Switch, START - 230V
5 32400.0002 1 Digital Timer, Brew - 120V
32400.0003 1 Digital Timer, Brew - 230V
01388.0000 2 Screw, Pan Head #6-32 x .75”
01510.0000 2 Lockwasher, External Tooth #6
6 01309.0000 1 Screw, PNH w/ Term WSHR #10-32 x .50”
00971.0000 1 Nut, Keps #10-32
7 01685.0000 1 Connector, Power Cord
8 01637.0006 1 Power Cord 6.0’ - 120V
01637.0002 1 Power Cord 7.0’ - 120V
27728.0001 1 Power Cord - 230V
9 00603.0000 1 Clamp, Nylon
10 01533.0000 2 Spacer
11 06064.0000 1 Label, Cord Warning
12 27705.0000 1 Terminal Lug - 230V
02308.0000 1 Screw, Pan Head #8-32 x .38”
13 00824.0000* 2 Decal, Ground
Items listed below are not serviced.
14 01668.0000 2 Wire Nut, Orange, Warmer Blanket Wires to Main Harness
15 10301.0000 1 Wiring Harness, Main - 120V
10301.0003 1 Wiring Harness, Main - 230V
16 21000.0725 1 Lead, Elec - 18 AWG BLK 12.0”, Warmer Blanket to Main Harness - 120V
21000.0421 1 Lead, Elec - 18 AWG BLK 12.0”, Warmer Blanket to Main Harness - 230V
17 21001.0723 1 Lead, Elec - 18 AWG WHI 12.0”, Warmer Blanket to Main Harness - 120V
21001.0173 1 Lead, Elec - 18 AWG WHI 12.0”, Warmer Blanket to Main Harness - 230V
37238 090205
Mounting
(Continued)
