Page 23
41722 070209
SCHEMATIC WIRING DIAGRAM TB3, TB3B, TB3-LP
OPTIONAL
READY
INDICATOR
SWITCH &
THERMOSTAT
LIMIT
THERMOSTAT
"KEEP WARM" HEATER
ON/OFF SWITCH
37234.0007A 02/08 © 2008 BUNN-O-MATIC CORPORATION
START
SWITCH
DILUTION
BREW/DILUTION
TIMER
BREW
TANK HEATER
BLU/BLK BLKBLK
BLK
6 5 4 3 2 1
WHI
WHI WHI
WHI/VIO
WHI/BLU
WHI/ORN
WHI/YEL
WHI/VIO
WHI/VIO
WHI/GRN
WHI
WHI
L1 N
100 VOLTS AC
120 VOLTS AC
2 WIRE + GND
SINGLE PHASE
BLU/BLK BLK
GRN
Chassis Ground
Earth Ground
SOL
SOL
