Bunn VP17 - SCHEMATIC WIRING DIAGRAM; VP17-1;-2;-3 Wiring Diagram

Page 17
10860 061501
SCHEMATIC WIRING DIAGRAM
VP17-1/-2/-3
10862.0003H 09/06 ©1997 BUNN-O-MATIC CORPORATION
WHI
WHIWHI
WHI
WHI
WHI
LOWER WARMER
N
WHI
120 VOLTS AC
2 WIRE + GND
SINGLE PHASE
BLK BRN/BLK BRN/BLK
BLK
VIO VIO
VP17-3 2 SIDE WARMERS
1320W
BLK
TANK HEATER
L1
GRN
BLK BLU
SW. & THERMOSTAT
ON/OFF SWITCH
WHI/RED
"KEEP WARM" HEATER
50W
WHI
BLK
LIMIT
THERMOSTAT
WHI
REAR WARMER
WHI
WHI
P3 P1
VIO
BLK
VP17-2 TOP WARMER ASSY
VIO WHI
ON/OFF SWITCH
ON/OFF SWITCH
ON/OFF SWITCH
NOT USED ON LATE MODELS
WITH SIDE WARMERS
FRONT WARMER
REAR WARMER
