5
Burley Cub Owner’s Instruction and Safety Manual
2. Secure it and lock the pin by
rotating it toward the rear of the
trailer as shown in the drawing on
the right.
3. Slip the safety pin though the
forward hole in the tongue and
lock in place. Refer to the illustra
tion showing the locked position
of the safety pin. Firmly pull on the
tongue to ensure that it is secure.
Important: The tongue retaining pin is captured between
the tongue receptacle and the lip of the poly shell. It should
never be completely removed from the tongue receptacle.
Tongue retaining pin must be locked into place before using
trailer. If pin is not properly locked, trailer could separate from
bicycle, resulting in an accident or serious injury. Safety pin is a
backup for the retaining pin. Under no circumstances should the
trailer be towed with only the safety pin engaged.
Installing the Safety Flag
Insert the safety fl ag pole through the loop of ½” webbing on the outside of the
trailer and into the fl ag pocket at the bottom left hand corner of the trailer as shown
below. DO NOT USE YOUR TRAILER WITHOUT THE SAFETY FLAG IN PLACE.
1
2
3
Forward hole in tongue
Retaining Pin
Safety Pin
OPEN
LOCKED
