6
Burley Cub Owner’s Instruction and Safety Manual
IV. Unfolding & Folding Your Burley Cub
Unfolding your Burley Cub
Your Burley Cub is designed with a durable
polyethelyne bucket, lightweight alumi-
num frame with roll cage, and bright-col-
ored polyester software. Setting it up or
folding it down is accomplished in a few
easy steps as follows:
To unfold, rotate the front tube
upward and the rear tube back
until they meet on the two black
plastic saddles as shown at right.
Then rotate the two frame locks to
snap onto the rear tube as shown.
The frame locks should connect
adjacent to, and to the outside of
the two plastic saddles.
Check that the frame locks are properly engaged before using
trailer. Failure to do so can result in serious injury.
Installation and Use of the Cover
Your Big Screen 2-in-1 Cover is held in place by eight snaps at the rear, top, and two
sets in the front. Always use your cover to keep debris out (and toys inside) of the
trailer when it’s in use.
Frame locks
snapped into
closed position
onto rear tube.
Frame Lock
