4.
Trailercycle Rack Installation:
1. Attach bottom of rack to holes in bicycle dropouts using washers and socket head bolts provided.
2. Position top of rack parallel to the ground. WARNING: RACK MUST BE LEVEL. WHEN PULLING
A TRAILERCYCLE, A NON-LEVEL RACK CAN ADVERSELY AFFECT BICYCLE HANDLING,
RESULTING IN AN ACCIDENT OR SERIOUS INJURY.
3. Attach rack stays to rack and bicycle with provided washers and socket head bolts or use band
clamps to attach rack stays to seat stays.
4. If stays protrude above top of rack, excess length can be trimmed. To trim, mark stays, remove
from rack, cut with a hacksaw, then reinstall stays.
5. Tighten all fasteners to 4-5 N·m (3-3.7 ft-lb).
1
2
3
4
