BURNHARD WAYNE - Description of Components

5
DESCRIPTION OF COMPONENTS
Ref. Beschreibung Menge Ref. Beschreibung Menge
1 Bottle opener front shell 1 13 Rubber spacer 4
2 Bottle opener rear shell 1 14 Cart handle 1
3 Frame assembly 1 15 Right front foot cover 1
4 Right side shelf 1 16 Right rear foot cover 1
5 Left side shelf assembly 1 17 Rubber 2
6 Locking clip 2 18 Wheel cover 2
7 Leg mounting seats assembly 4 19 Wheel 2
8 Locking strap 1 20 Axle 1
9 Locking mechanism 1 21 Gas pipe strap 1
10 Folding lock 1 22 Double wrench 2
11 Left cart leg assembly 1 23 Wrench 1
12 Right cart leg assembly 1
Note that some parts are pre-assembled.
