Operation
| 1473-1-7878
— 4 —
Pos: 13 /Busch-Jaeger (Neustruktur)/Modul-S truktur/Online- Dokumentation/ Überschriften (--> Für alle Doku mente <--)/1. Ebene/A - F/Bedi enung @ 11\mod_12791855416 49_15.docx @ 83043 @ 1 @ 1
3 Operation
Pos: 14 /Busch-Jaeger (Neustruktur)/Modul-S truktur/Online- Dokumentation/Bedi enung/Sonstige Ber eiche/Bedienung - Rute nbeck Kompakt-Universa l-Anschlussdosen @ 23\ mod_1333349390750_15. docx @ 207533 @ 2 @ 1
Caution
Use only patch cables with plugs which, according to the manufacturer's specifications, meet the
valid EN/IEC standards.
- The use of non-standard components voids the warranty.
1. Insert the plug of the connecting conductor from the signal source into the connecting socket.
2. Insert the plug of the connecting conductor from the player into the connecting socket.
3. Insert the plugs into the socket with as little force as possible to avoid twisting or tilting the contacts in the
plug.
Pos: 15 /Busch-Jaeger (Neustruktur)/Modul-S truktur/Online-Dok umentation/Übersc hriften (--> Für alle Dokument e <--)/1. Ebene/S - T/Technisc he Daten @ 11\mod_1279185386 320_15.docx @ 83019 @ 11 @ 1
4 Technical data
Pos: 16 /Busch-Jaeger (Neustruktur)/Modul-S truktur/Online- Dokumentation/ Technische Daten/Sons tige Bereiche/Techni sche Daten - Rutenbeck Kompa kt-Universal-Anschlus sdosen @ 23\mod_13331107 90095_15.docx @ 207441 @ 21 @ 1
Designation
Value
Screen housing
Die-cast zinc
Housing
ABS form mass, die-cast zinc
Screen connection / strain
relief
360° contacting, contacting bracket for data cable with ø 6-10 mm, strain relief via cable ties
Cable diameter
6-10 mm
Wire diameter
AWG 26 – AWG 22
Operating temperature
-40°C to +70°C
Protection type according to
DIN EN 60 529
IP21
Dimensions
80.8 mm (Width) x 80.8 mm (Height) x 42.4 mm (Depth)
Construction
DIN IEC 60 603-7-51 Ed. 1
