BUSCH R5 Aqua - 3 Product Description

Product Description | 3
0870524638_RA_Aqua_A0003_IMS_en 5 / 12
3 Product Description
INIF GB1 GB2
WS
OUTTS
INIF GB
WS
OUT
TS
RA 0165-0305 D Aqua
RA 0400-0630 C Aqua
IN
IF GB1
WS1
OUT1GB2WS2OUT2
RA 1000-1600 B Aqua
CD2
CD1
CD
CD
IN Suction connection IF Inlet filter
OUT Discharge connection CD Condensate drain
TS Temperature switch WS Water separator
NOTE
Illustrations
In this instruction manual the illustrations may differ from the machine appearance.
