Bush Classic KTS-607 - Playing Records; Turntable Operation Notes

Using the turntable
1. Place the turntable case on a flat level surface.
2. Insert the adaptor cord into the DC jack at the rear of the
case and plug the adaptor into the mains supply socket
3. On first use, ensure that the cable tie is removed from the
player arm
4. Remove the stylus cover (fig. 1) and keep in a safe place
for future use
5. Move the speed selector to the speed (33, 45 or 78rpm)
corresponding to the record to be played
6. Turn the VOLUME knob to turn the turntable on and the
mode indicator will illuminate red
7. Place a record onto the turntable spindle and unclip the
tone arm(fig. 2)
8. Use the cuing lever to lift the tone arm (fig3) and move the
arm (fig 4)so that the stylus is positioned just inside the edge
of the record or aligned with the start of the track to be
played.
9.
10.
11.
When the end of the record has been reached the
turntable will automatically stop.
12.
Use the lever again to lift the tone arm (the deck will start
to rotate again), move it back to the clip and lower into the
cradle. The deck will stop
13. Secure the tone arm using the clip and refit the stylus
cover after use and ALWAYS before moving the turntable
14. To turn off the turntable at any time, lift the tone arm on
the record and turn the VOLUME knob fully anticlockwise.
Note
Some records have larger centre hole and it may be
necessary to fit the centre hole adaptor to the turntable
shaft before placing the record on the turntable
Always refit the stylus cover and secure the turntable arm
using the clip before moving the turntable
Fig 1
Fig 2
Fig 3
Fig 4
9
Slowly lower the arm and after a short interval the record will
start to play
Adjust
the vol ume to the desired level by rotating the
volume control knob
W ood en Turntable W ith L eg s Instruction Manual
