BUSH HOG / MATERIAL HANDLING REPAIR PARTS MANUAL
1-20G-1
50042762 CABLE CONTROL VALVE KIT (cont. next page)
For Model 3045 Loader
Used on Kubota L4330, L4630 & L5030 Tractors
REF. PART
NO. NO.
QTY. DESCRIPTION
50040949 1 Hydraulic Kit (1-9)
1 50040940 1 Hydraulic Adaptor Block
2 44385 4 Capscrew M8 x 1.25 x 35 G8.8 ZP
3 25H42224 3 O-Rings
4 53338 2 90° Elbow (9/16” OMR - 9/16” JICMR)
5 63453 2 90° Elbow (9/16” JICMR - 9/16” JICFS)
6 3050137 3 Male Adaptor (9/16” ORB - 9/16” JICMR)
7 25H43928 2 Hydraulic Hose 40” (9/16” JIC - 9/16” JIC)
8 50040951 1 Hydraulic Hose 40” (9/16” JIC - 3/4” JIC)
9 52161 4 Cable Tie
10 50043973 1 Instruction Sheet
–––– 1 Control Handle & Cable Assembly (11, 12)
11 50043970 1 Control Handle Assembly (See separate parts list for handle parts)
12 50043972 1 Control Cable
–––– 1 Cable Connecting Kit (13-19)
13 50043989 1 Cap Kit
14 50027497 1 Flange Kit
15 50043988 1 Joint Kit
16 50043987 1 Pin
17 50043986 1 O-Ring
18 50027501 1 Washer
19 50043985 1 Screw M5 x 18
–––– 1 Valve & Mount Assembly (20-27)
20 50044570 1 Small Walvoil Valve (See separate parts list for valve parts)
21 50043965 1 Valve Cover
22 50043964 1 Valve Mount
23 50043003 4 O-Ring Coupler
24 50043004 1 Decal, Color Code
25 –––– 3 Capscrew 5/16” x 1-1/4”
26 –––– 3 Lockwasher 5/16”
27 –––– 3 Flatwasher 5/16”
–––– 1 Bag of Hardware
28 15080 2 Capscrew 1/2” x 2-1/4” Gr.5
29 15528 2 Hex Nut 5/16”
30 15806 2 Lockwasher 1/2”
31 15808 2 Lockwasher 5/16”
32 15812 3 Lockwasher 3/8”
33 15915 3 Flatwasher 3/8”
34 15916 1 Flatwasher 1/2”
35 44514 2 Capscrew 5/16” x 3-1/2” Gr.5
36 3050137 1 Male Adaptor (9/16” ORB - 9/16” JICMR)
37 5161212 3 Carriage Bolt 3/8” x 1-1/4”
38 8151200 3 Hex Nut 3/8”
39 8151600 2 Hex Nut 1/2”
40 25H42696 1 Straight Adapter
41 50043953 1 Washer Plate
42 50043963 1 Grommet
43 50043967 1 Handle Mount Plate w/ Decal
44 25H41276 1 Valve Control Decal
50044749 1 Hose Connection Assembly (See Valve Plumbing Assembly
for Small Walvoil Valve without Handle)
SEPTEMBER, 2006
