This document is an instruction manual for the Bush b-3363G Home Theatre soundbar system. It provides guidance on setup, usage, technical specifications, and product support.

Function Description

The Bush b-3363G Home Theatre is a soundbar system designed to enhance audio output for televisions, MP3 players, smartphones, and other audio equipment. It includes a soundbar and an external wired subwoofer to deliver a more immersive audio experience. The system supports multiple input sources, including stereo RCA, optical, and 3.5mm line-in, as well as Bluetooth connectivity for wireless audio streaming. It features a remote control for convenient operation and offers various sound modes optimized for movies, music, and dialogue. The soundbar can be wall-mounted for flexible placement.

Important Technical Specifications

Amplifier:

Power output: 100W RMS
Frequency response: 20Hz - 20KHz ± 3dB
Input sensitivity: 1000mV

Main unit (Soundbar):

Power supply: INPUT: 100-240V ~ 50-60Hz, OUTPUT: 24V 2.5 A
Power consumption: 60W
Standby power consumption: < 0.5W
Full range speaker drivers: Impedance: 4 Ohm, 52mm (2"); Frequency response: 180 Hz ~ 20KHz
Dimensions: 940 x 68 x 60mm

Subwoofer:

Impedance: 4 Ohm, 120mm (4.75")
Frequency response: 35~180Hz
Dimensions: 172 x 352 x 320mm

General:

Mains cable length: 1 metre
Remote control battery: 1 x CR2032
Bluetooth compatibility: EDR, GFSK, π/4-DQPSK, 8DPSK
Bluetooth version: 2.1
Bluetooth operation range: Approximately 10 meters (30 Feet)

Usage Features

Getting Started:

The manual emphasizes a simple, step-by-step setup process.
Accessories included: Soundbar, external subwoofer, remote control, CR2032 battery, RCA audio cable, digital optical audio cable, 3.5mm audio cable, mains adapter, and instruction manual.

Control Panel and Remote Control:

Soundbar Controls:
- Stereo RCA Audio inputs (L/R AUX IN)
- OPTICAL IN
- DC Power input
- Subwoofer Output (SUB OUT)
- Power and Source button: Press and hold 2 seconds for ON/OFF; single touch to select input (BT, Aux in, Line in, Optical in).
- Volume + and - buttons.
- Pair button: Initiates Bluetooth pairing.
- 3.5mm LINE input.
Remote Control Functions:
- Power: ON/OFF.
- Mute.
- Skip (forward/back) in Bluetooth mode.
- Play/Pause in Bluetooth mode.
- Pair: Activates Bluetooth pairing mode.
- Volume +/-.
- Source: Selects input (Optical, Line In, AUX in, Bluetooth).
- Voice: EQ optimized for dialogue.
- Movie: EQ optimized for movie sound.
- Music: EQ optimized for music.
- Bass +/-: Adjusts bass levels.

Connecting the System:

Wired Subwoofer: Connects to the soundbar via an RCA audio cable to the SUB OUT port. The soundbar automatically uses the connected subwoofer when audio is played.
Stereo RCA Inputs (AUX IN): Connects to audio outputs of a TV or other devices using the supplied RCA cable.
Optical Input: Connects to a TV or audio source with an optical audio output using the supplied digital optical audio cable. Requires setting the audio source to PCM or Optical Audio.
Line In (3.5mm): Connects to MP3 players, smartphones, or other audio sources using the supplied 3.5mm audio cable. Disconnects other cables when in use.
Bluetooth Pairing:
1. Switch on the unit.
2. Select Bluetooth mode via the SOURCE button (blue light indicator).
3. Press the PAIR button on the remote or unit (flashing blue light).
4. Select "b-3363G" on your Bluetooth device to pair.
5. A beep confirms successful pairing, and the indicator turns solid blue.
6. The unit remains paired unless manually unpaired or reset.
Controlling a Paired Bluetooth Device: Playback, skip tracks, and pause can be controlled via the remote or the audio device itself. Volume output is affected by the source device's volume level (recommended 70-80%).

Source Indicator Lights:

Red Light: Power Off
Orange Light: Optical Mode
White Light: Aux In Mode
Green Light: Line In Mode
Flashing Blue Light: Bluetooth Pairing
Blue Light: Bluetooth Connected

Wall Mounting:

Includes wall fixing screws and wall mount brackets.
Requires careful installation by a qualified person to avoid damage and ensure structural integrity.
Important to check for hidden wires/pipes before drilling.

Maintenance Features

Care & Maintenance:

After Use: Set the soundbar to Standby. Unplug from mains if leaving unattended for long periods (e.g., holidays).
Battery Care: Remove the remote control battery if the unit is left unattended for long periods to prevent leakage and damage.
Cleaning: Unplug the unit from mains power before cleaning. Wipe the cabinet with a lint-free duster. Do not use liquids or solvents.

Troubleshooting:

No Power: Check mains plug connection and power to the socket.
No Sound:
- Ensure external source volume is up and outputting sound (for AUX input).
- Check soundbar volume.
- For digital optical input, ensure source DIGITAL output is set to PCM, LPCM, PCM 2Ch stereo, or PCM downmix.
- For Bluetooth, verify device is paired.
No Response from Soundbar: Unplug power cable for 1 minute, then plug back in.
Remote Control Not Working:
- Reduce distance to the main unit.
- Check battery installation.
- Replace battery (CR2032 lithium).
- Aim remote directly at the soundbar.
Unit Powers Off After 20 Minutes: This is a power-saving feature (STANDBY mode after 20 minutes of inactivity). Press the STANDBY button to wake the unit.

Safety Information:

Double insulated, no earth connection required.
Connect to 100-240V 50/60Hz AC supply.
Unplug during lightning storms or long periods of disuse.
Avoid opening covers to prevent exposure to dangerous voltages.
Prevent fire/electric shock by avoiding overloaded outlets/extension cords.
Use suitable power sources as marked.
Ensure supply voltage matches technical specifications.
If plug is unsuitable, consult a qualified electrician.
Completely disconnect from mains by switching off outlet and removing plug.
Do not bend, stretch, or pull supply cable.
Power socket must be easily accessible.
Allow adequate ventilation; do not install in confined spaces.
For indoor use only.
Heat Build-up: Unit may heat up during continuous high-volume use; avoid touching to prevent burns.
Colour Irregularity on TV Screen: If seen, turn TV off for 15-30 minutes, then on again. If still present, move soundbar further from TV.
Moisture and Water: Do not use near water, bathtubs, sinks, wet basements, or swimming pools.
Heat Sources and Flames: Batteries should not be exposed to excessive heat. Avoid overloading outlets.
Servicing and Repairs: Refer all servicing to qualified personnel. Servicing is required if the apparatus is damaged (liquid spills, objects fallen in, rain exposure, abnormal operation, dropped).

Disposal:

Product is designed with high-quality, recyclable materials.
Indicates compliance with European Directive 2002/96/EC (crossed-out wheeled bin symbol).
Dispose of old products according to local regulations, not normal household waste, to prevent negative environmental and health consequences.

Declaration of Conformance:

Argos Ltd. declares compliance with essential requirements of Directive RED 2014/53/EC.
The complete declaration is available at www.argos-support.co.uk.
Bluetooth® word mark and logos are registered trademarks of Bluetooth SIG, Inc.
CE marking indicates compliance with essential requirements for Radio Equipment and Telecommunications Terminal Equipment Directive RED 2014/53/EC for use within the UK.

Product Support:

Online support: www.argos-support.co.uk
Helpline: 0345 604 0105 (8am-7pm Mon-Sat, 10am-4pm Sun).
Requires model reference (b-3363G), serial number, and date of purchase for assistance.
Provides a 12-month guarantee against faults and breakdowns, subject to conditions (e.g., correct installation, domestic use, no accidental damage, no inexpert repair).
Includes important data protection information regarding personal data processing.
