To replace the battery, remove the cap on the brightness adjustment control knob using a
coin (Fig. 2), and insert a CR2032 battery with the “+” mark facing up.
THE DOA LR600, LR600-i and LR800 RETICLES
The new DOA LR reticle series gives hunters and shooters a series of aiming points at multiple yardages that compensate for
bullet drop and correspond to the ballistics of popular centerfire rifle calibers and loads. These aiming points allow users of
DOA LR reticles to increase the probability of first round hits at extended ranges and expand their effective range. Along with
their holdover points, DOA LR reticles now include windage markings that help long range shooters compensate for the effects
of wind at ranges from 200 to 800 yards. The illuminated DOA LR600-i reticle provides the ultimate in low light performance
for hunters seeking an edge when available shooting light is at a minimum.
SIGHTING IN / AIMING POINTS
DOA LR600/LR600-i & DOA LR800 reticles are intended to be sighted in at 100 yards, and
provide aiming points out to 600 yds (LR600 and LR600-i) or 800 yds (LR800). The reticles
have numeric markings indicating holdover points at 100 hundred yard increments. The user
can sight-in at 100 yds on any magnification setting, but for the ballistic reticle feature
(range and windage marks) to function properly, the scope’s magnification must be set to
the highest power. The correct settings for the scopes that include the DOA reticle are shown
in the chart on the right:
Fig. 2
Model Set to:
2.5-10x 44mm 10x
4-16x 44mm 16x
2.5-15x 50mm 15x
6-24x 50mm 24x
