TROUBLESHOOTING
Symptom Solution
Motor does not work. Check to make sure machine is plugged
in. Check to make sure the power
button is turned on.
The pouch is jammed. Please slide the ABS and pull out the
pouch from the front of the machine
SPECIFICATIONS
Model Name BSN20892 BSN20893
Power Supply Voltage 120V 60Hz / 220-240V 50Hz
Power Consumption (W) 265 W 365 W
# of Rollers 2
Min Pouch Size Credit card size (54 x 86 mm)
Speed 9.8” (250 mm)
Maximum Entry Width 9” (230 mm) 13” (330.2 mm)
Warm-up Time (Min)
3-5 minutes
Lamination Hot and Cold
Unit Dimensions
(W x D x H)
13.8” x 5.7” x 2.9”
(350 x 145 x 74 mm)
17.4” x 5.7” x 2.9”
(443 x 145 x 74 mm)
Unit Weight 2.5 lbs (1.15 kg) 3.6 lbs (1.63 kg)
ENGLISH Model • 20892/20893
4
