300 mm
ATTENTION: Water must not get in-
to the waste air outlet in the ounter
wall. For safety reasons water
must be prevented from entering
the room where the motor is. A life-
threatening electric shock could
be the result.
Exhausting pipe 100 mm
Muffler
Exhaust air grating
220 - 240 Volt
24 Volt Control lead
suction pipe
outer wall
Mounting panel
Installation of the BVC exhaust air muffler
