REF DESCRIPTION
1 Mirror skimmer body, liner
2 Small mouth (extension throat 145 mm)
3 Wide mouth, skimmer, liner
4 Wide mouth ange gasket, mirror skimmer
5 Wide mouth ange, mirror skimmer
6 Screw FZ ST 5.5 x 25 A4
7 Face trim, wide mouth mirror skimmer, liner
8 Skimmer weir
9 Weir stop
10 Shutter
11 Screw FZ ST 5.5 x 25 A4
12 Skimmer basket, straight handle
13 Lid housing
14 Lid
15 Support column
SL-119-MR
15
