1. Rear Corner Sensor
2. Rear Central Sensor
Parking Assistance Switch
Parking Assistance Switch is on 1#
switch group, and 1# switch group
located on the top of central control
panel.
When the power supply is at ―ON‖ and
the gear lever on R, the system enters
working status
ON:After pressing the switch , the
car-shaped icon will be lightened
and the buzzer sound once.
OFF: press the switch again.
Display
when any barriers are detected by the
sensor, according to the shape of
barrier and distance between the car
and the barrier, indicator will light up
on 1# switch group, and icon will
display on touch screen (optional).
1. Rear corner sensor working
2. Rear central sensor working
Reversing Radar System
Icon display on touch screen
(optional)
During reversing, the screen will
display video of vehicle reverse, and
reverse reward warning icon will
appeared on the left and top of the
screen.
