4
ASSEMBLY
Tools Required
8 mm ring spanner, 10 mm ring spanner, 15mm pedal spanner, 14 mm open end spanner, 5 mm hex key, 6 mm hex key, screw
driver, cutters/plier
Set Up.
Install front wheel
It is important that you fit the front wheel with the axle locked to the fork with the anti-rotation locking washers. (Washer with
locating lug as shown in photo 1)
The pressure of the nuts alone will not prevent the axle turning and pulling the electrical cable from the motor. If that occurs,
the damage is irreparable and not covered by warranty.
Locating Lug
