C&K Securitech
13
OPTION 7-4. EUROPEAN OPTIONS.
74-1 Flash the LED relating to a zone if that zone if it is OPEN when the
control panel is in an UNSET condition
74-2 ⊗ 2 Stage Communicator output
74-3 10 minute auto isolate of an open zone when set.
74-4 BLOCKSCHLOSS - German Setting Method.
BELLBOX CONNECTIONS
ACTIVE 5 PANEL ST- S- BELL+
LEFT HAND
TAMPER
RIGHT HAND
TAMPER
SONADE 2000 STROBE- B D A T
FLASHGUARD XL+ STROBE- SIREN- SUPPLY+ SUPPLY- TAMPER
OUT
STARLIGHT 2000 ST -R +H -H RTN
ACTIVEGUARD STB- -S +12V -12V RIGHT
HAND
TAMPER
ACTIVE GUARD 3 ST- -SW V+ V- RET
SECURIGUARD STROBE- S- SUPPLY+ SUPPLY- LEFT
HAND
TAMPER
NOVA GUARD 2+T STROBE- S- 12V+ 12V- R
SPIRIT AU1000 STB- TRG- HOLD
OFF +
HOLD
OFF -
RTN-
GENERAL
TERMINALS
STROBE
TRIG -
SIREN
TRIG -
SUPPLY+ SUPPLY- TAMPER
RETURN
You MUST check your bellbox instructions to see if you are required to make
any other links.
These terminals are given in good faith but without warranty. The manufacturers
of the bellboxes shown above have the right to change terminals without
notification to C&K systems or to you, the end user.
This product should only be used for domestic, commercial and
light industrial use only.
