C&K Securitech
2
FACTORY DEFAULTS
User / Customer Code 1 1234
Engineer Code 7890
Circuit 1 Personal Attack (PA)
Circuit 2 Alarm circuit
Circuit 3 Alarm circuit isolated in home set
Circuit 4 Alarm circuit with walkthrough
Circuit 5 Entry / Exit circuit
Full set exit time 30 seconds
Night set exit time 15 seconds
Entry time 30 seconds
Bell ring time 15 minutes
These programming defaults are what the panel will revert to if a factory reset is
performed. The panel should come to you programmed in this way however if for
some reason you find it not to be the same, simply perform a factory reset and
this will revert the panel to the above settings.
SPECIFICATION FOR SOFTWARE REVISION NUMBER V3.0
The software revision number can be located on the top of the main processor
Power Supply
Mains Supply Voltage 230 v AC Nom
PSU output voltage 13.6 v DC Nom
Maximum output current 1 amp (total)
Aux current 500 mA Max.
Battery Fuse 1 A (20 mm)
Panel Quiescent 40 mA
Maximum Cable Run 100 Metres
General
Operating temperature 10 to 50 degrees centigrade
Humidity Up to 80% non condensing
Dimensions 304 mm (W)
220 mm (H)
89 mm (D)
Control Panel Weight 1.45 kg Excluding Batt
Stand by Battery 2.6 Ah 12 v Rechargeable
6 Ah max.
