Page 20 CCRadio 2E
Specifications
FREQUENCY COVERAGE
FM Band: 87.5 - 108 MHz Stereo
AM Band: 520 - 1710 kHz
Ham (VHF): 144 - 148 MHz
WEATHER BAND
Channel 1: 162.400 MHz Channel 5: 162.500 MHz
Channel 2: 162.425 MHz Channel 6: 162.525 MHz
Channel 3: 162.450 MHz Channel 7: 162.550 MHz
Channel 4: 162.475 MHz
ROTARY TUNING KNOB RESOLUTION
AM - 1 kHz Ham (VHF) - 5 kHz
FM - 50 kHz WX - 1 Channel
POWER SOURCE
AC 120 Volts 60Hz
Batteries: (4) “D” size
POWER CONSUMPTION
AC Power: 8 Watts
Battery Power: 40-50 mA DC
AUDIO
10% THD at output power @ 1.8 Watt AC typical
@ 0.9 Watt Battery
Speaker: 5", 4 Ohm, 6 Watts
ANTENNA
FM, Ham (VHF) and Weather Band: Telescopic whip antenna
AM Band: 1) Built-in Ferrite Bar - 7/16" dia x 8" long (200 mm)
2) External AM antenna directly wired through filter
network into RF front end.
DIMENSIONS
11" W x 6-1/2" H x 4" D (at the base)
WEIGHT
Approximately 3.8 pounds without batteries
