CD TRANSPORT TL3N
14
●AES/EBU Connection
2.0
2.0
2.0
Clock Generator
●COAXIAL Connection
Connect to the COAXIAL terminal of the D/A converter
with a 75Ω COAXIAL (RCA) cable.
●TOS LINK Connection
Connect to the TOS LINK terminal of the D/A converter
with an optical cable.
●WORD CLOCK Connection
Connect to the AES/EBU terminal of the D/A
converter with a 110Ω XLR cable.
Connect to the BNC terminal of the clock
generator with a 75Ω BNC cable.
