18
With Dip 2 OFF = auto close disabled, the open, close and stop commands are sent with the remote control or button.
MEMORIZING TRANSMITTERS
With the door closed, hold down MEMO RX and press the desired transmitter button within 5 sec.; the courtesy lamp will
flash to confirm memorization.
Repeat for each separate transmitter. Up to 20 different codes can be stored in this way.
TO DELETE A TRANSMITTER: hold down MEMO RX until the courtesy light turns on, then press the transmitter button;
the courtesy light flashes 3 times to confirm the deletion - now release the MEMO RX button.
RESETTING MEMORY: resets memory by deleting all memorized codes - hold down MEMO RX until the courtesy light
goes out
- the courtesy light flashes 9 times to confirm that the memory has been reset - now release the MEMO RX button.
COURTESY LIGHT SIGNALS
no FLASH = transmitter to memorize.
1 FLASH = transmitter memorized.
2 FLASHES = a previously memorized transmitter is being re-memorized.
3 FLASHES = a transmitter has been deleted.
4 FLASHES = in delete mode, transmitter not memorized.
5 FLASHES = memory full.
9 FLASHES = all memorized codes deleted.
OPTIONAL ACCESSORIES
Tilt-up doors
The DUMPER automation can also be installed to tilt-up doors; in this case you must install the AU.C25 adapter to the
door as shown in figure 17.
In order to join the bent arm of the DUMPER to the straight arm provided with the accessory AU.25 it is necessary to cut
the bent drive as shown in picture number 17 and using the straight arm as template, drill 2 holes of 6 mm of diameter and
so join the 2 arms (the screws are not provided).
Emergency battery kit
An emergency battery kit is available (code DM.BT) to allow the automation to work even during mains power failures.
Fit the batteries in their compartments and hook them up as shown in Figure 18.
TECHNICAL DATA DUMPER 7 DUMPER 10
Power 115 - 230V AC 50/60 Hz 115 - 230V AC 50/60 Hz
Motor feed 24Vdc 24Vdc
Power draw 1 A 1,5 A
Standby power draw 1W without accessories
3W with accessories
1W without accessories
3W with accessories
Traction/thrust 700 N 1000 N
Maximum stroke 2700 mm - 3700 mm 2700 mm - 3700 mm
Accessory power 24 V =/O.5A max 24 V =/O.5A max
Opening speed 0.12 - 0.20 m/s 0.12 - 0.20 m/s
Closing speed 0.12 - 0.20 m/s 0.12 - 0.20 m/s
Maximum load 9 sqm 12 sqm
Intermittency Intensive Use Intensive Use
Operating temperature -20°C/+50°C -20°C/+50°C
Protection rating IP 10 IP 10
Noise level
>60dB >60dB
Weight 1.6 kg 1.6 kg
