10
3. HOW TO SECURE THE SMOKE VISOR
3.1 Repeat steps 2.1 e 2.2
3.2 Introduce the left side arm of the smoke visor in line with its seat
until the brass screw is visible (Pic.5). Tighten the screw C to
secure the smoke visor arm to the movement lever. (Pic.3)
3.3 Place the smoke visor on the opposite side by pressing gently.
3.4 Secure the clear visor as indicated in step 1
WARININGS! Do not use the smoke visor during late night hours
or in scarce visibility condition.
WARNINGS! Any adjustments to the smoke visor must be done in
still position.
4. HOW TO REMOVE THE WASHABLE LINING.
To remove the inner padding you can start either from the
right or left side.
4.1 Remove the cheek pad by pulling it inwards and detach the
studs in the back. Repeat the same step on the opposite side
(Pic.6).
4.2 Starting from the neck device, remove the lining by pulling
slightly towards the inside of the helmet (Pic.7). Still pulling
gently, release also the lateral fixing strips F and the fixing pla-
stic frame in the front E (Pic.8).
4.3 Remove completely the lining.
ENG
