1. HOW TO FIX AND REMOVE THE CLEAR VISOR.
1.1 Open the visor until the small arrow on the mechanism mat-
ches the sign on the visor. Press the release button A and pull
it backwards (Pic.1) then release the visor.
1.2 In order to remove the visor entirely, repeat the above step on
the opposite side.
1.3 Repeat the above steps in reverse order to mount back the
clear visor.
2. HOW TO REMOVE THE SMOKE VISOR
2.1 Open the clear visor. Press the button B upwards while pulling
kindly in order to remove the visor mechanism together with
the clear visor on one side (Pic.2)
2.2 Repeat the above step on the opposite side to remove com-
pletely the visor mechanism with the clear visor.
2.3 With the smoke visor lowered unscrew the screw C then
release the movement lever D (Pic.3).
2.4 Starting from the side of the movement lever, lower the smoke
visor even further beyond the front edge rim of the shell and
then extract it by pulling it gently. (Pic.4).
