Technical Specification
PHYSICAL
129 x 41 x 200 mm, 5” x 1.6” x 7.9”, occupies 1 770 Rack slot or a
769 Chassis, 0.6 Kg, 1.3 Lbs.
ENVIRONMENTAL
0°C to 40°C, 32°F - 104°F (enclosure ambient).
Internal temperature monitoring via web page.
POWER
17 W (from 770 rack or 769 single ‘Blade’ chassis)
LAN
RJ45 802.3 100/1000 Base-T Auto MDIX.
Static or DHCP IP Addresses.
TTL and DSCP QoS stream tagging.
NETWORK PROTOCOLS
UDP, TCP, ARP, DHCP, ICMP, IGMP V2/V3, HTTP, Telnet, SNMP, SMTP,
DSCP
HDMI INPUT
HDMI 1.3, 480i – 1080p60, 600x480p60, 800x600 p60, 1024x768p60
HDCP 1.4
VIDEO ENCODING
MPEG 4-10/H.264 MP@L4, CBR/VBR encoding, supported bit rates 50
Kbps - 20 Mbps
AUDIO ENCODING
AAC Encoding, 32, 44.1, 48 KHz sampling, 96 – 320 Kbps
OUTPUT STREAM
480i – 1080p60 Unicast or Multicast UDP MPEG2 transport stream.
Stream produced with HDCP Pro content protection on HDCP Pro
enabled encoders.
HDMI OUTPUT PORT
Local HDMI monitor port
USB
USB 3.0 host port used for keyboard/Mouse, software upgrade via
memory stick.
RS232 PORT
Rx, Tx, CTS, RTS up to 11,5200 Baud Configured for SIPI external
configuration/control OR IP to RS232 bidirectional pass through for
external device control.
FRONT PANEL
LCD Display and 3 push buttons for local configuration.
WEB PAGE
CONFIGURATION
Configuration web pages for easy setup.
EVENT MONITORING
Key operational warnings reported via SNMP traps sent to third party
SNMP manager (MIB available via link on unit’s SNMP web page).
Automatic e-mail of Event log files via external SMTP server.
SOFTWARE
Fully upgradable with ONLY protected MediaStar software from an HTTP
server or local USB memory key.
APPROVALS
FCC, CE, RCM, CB, TUV Approved as part of 770 rack or 769 single
‘Blade’ chassis.
