INDOOR UNIT PART NAMES
Indoor unit
Part Name
1. Front Panel
2. Aux. Button
3. Filter
4. Remote Controller
5. Inter-Connection Wire
6. Drain Hose
7. Refrigerant Lines
Outdoor unit
4
Air outlet
Air inlet
Air inlet
Air outlet
3
1
2
5
6
7
Fig. 1 - Indoor/Outdoor Unit
DISPLAY PANELS
NOTE: The display panel on the indoor unit can be turned on or off using the LIGHT button on the remote control.
* The temperature readout will be replaced by an error code if there is a malfunction.
