32
11.1.2 Multi Flash in Master and Slave
Modes
An RF60X in Master mode will cause
a Slave RF60X that uses the same RF
channel to synchronize to Multi mode
settings.
1. To enter Multi mode on the RF60X
M a st e r, p r e s s until you see
<MASTER> displayed as the group
na me.
2. Press the button once.
The LCD of the RF60X Master and
Slave units will show and
. Both Master and Slave units
are now in Multi Flash mode.
3. On the RF60X Master, follow the
steps in 11.1.1 to adjust the
n u m b e r of a s h e s a n d a s h
frequency per second (Hz). The
a s h f r e q u e n c y w i l l a p pl y t o b ot h
Master and Slave units in all
active g roups.
4. To exit Multi mode, press
twice to return to the
main screen.
Notes:
1. W h e n th e n u m b er of a s h e s i s
larger than that supported by
the power level of a particular
slave group, it will be reduced
accordingly for that particular
slave (see table Maximum Number
of Multi Flashes on page 29-30).
