Cadence MONO CLASS D - Page 12

BASIC SPEAKER WIRING DIAGRAMS FOR VARIOUS LOADS12
4 OHM
8 OHM
2 OHM4 OHM
1 OHM
TO
AMPLIFIER
2 OHM
TO
AMPLIFIER
4 OHM
TO
AMPLIFIER
8 OHM
TO
AMPLIFIER
1 OHM
TO
AMPLIFIER
2 OHM
TO
AMPLIFIER
+
+
+
+
++
-
-
-
-
--
4 OHM
8 OHM
4 OHM
8 OHM
4 OHM
8 OHM
2 OHM4 OHM
PARALLEL: SINGLE VOICE COIL SPEAKERS
NOTES ABOUT USING MUTLTIPLE SPEAKERS:
SERIES:
SINGLE VOICE COIL
SPEAKERS
SERIES:
DUAL VOICE COIL
SPEAKERS
2 OHM
4 OHM
2 OHM
4 OHM
4+4
OHM
2+2
OHM
1+1
OHM
8 OHM
TO
AMPLIFIER
4 OHM
TO
AMPLIFIER
2 OHM
TO
AMPLIFIER
+
+
+
-
-
-
Please note that the minimum impedance load for single Cadence Type RS amplifiers is 1 ohm.
If you choose to mono bridge two RS amplifiers into on load, the impedance should not be lower
than 2 ohm.
Lower impedance loads will cause overheating and may damage the amplifiers.
Do not use different type and different impedance speakers in the series and/or parallel
combinations shown, as unequal power sharing and acoustic outputs will result.
