Cadence MONO CLASS D - Page 13

ADVANCED SPEAKER WIRING DIAGRAMS FOR VARIOUS LOADS 13
PARALLEL:
DUAL VOICE COIL
SPEAKERS
3 X DUAL VC 8 OHM SPEAKERS WITH
PARALLEL VOICE COILS, IN PARALLEL
2 X DUAL VC 4 OHM SPEAKERS WITH
PARALLEL VOICE COILS, IN PARALLEL
4 X DUAL VC 8 OHM SPEAKERS WITH
SERIES VOICE COILS, ALL IN PARALLEL
2 X DUAL VC 2 OHM SPEAKERS WITH
SERIES VOICE COILS, ALL IN PARALLEL
2 X DUAL VC 1 OHM SPEAKERS WITH
SERIES VOICE COILS, ALL IN PARALLEL
4 X DUAL VC 4 OHM SPEAKERS WITH
SERIES VOICE COILS, ALL IN PARALLEL
4+4
OHM
2+2
OHM
8+8
OHM
4+4
OHM
8+8
OHM
4+4
OHM
8+8
OHM
2 OHM
TO
AMPLIFIER
1 OHM
TO
AMPLIFIER
2.67 OHM
TO
AMPLIFIER
1 OHM
TO
AMPLIFIER
+
+
++
-
-
--
4+4
OHM
2+2
OHM
1+1
OHM
2+2
OHM
4+4
OHM
2+2
OHM
1+1
OHM
2+2
OHM
4+4
OHM
2+2
OHM
4+4
OHM
2+2
OHM
2 OHM
TO
AMPLIFIER
2 OHM
TO
AMPLIFIER
1 OHM
TO
AMPLIFIER
1 OHM
TO
AMPLIFIER
++
+ +
--
- -
