37
Model 1027
Ref.
No.
Part No. Description
1 731-3209 Steering Wheel: Soft Grip
2 731-3210 Steering Wheel Cap
Ref.
No.
Part No. Description
1 731-1919 Steering Column: Black
2 731-1857 Control Knob
3 712-0142 Hex Nut 8-32
4 710-3217 Pan Head Machine Screw #8-32
5 710-0599 Hex Screw TT 1/4-20 x .50”
6 710-0514 Hex Screw 3/8-16 x 1.0”
7 712-0431 Lock Nut
8 749-1099 Bumper Tube: Front
2
4
3
1
5
6
5
8
7
7
NOTE: For painted parts, please refer to
the list of color codes below. Please add the
applicable color code, wherever needed, to
the part number to order a replacement part.
For instance, if a part, numbered 700-xxxx,
is painted Cub Yellow, the part number to
order would be 700-xxxx-0716.
Cub Yellow: 0716
Cub Beige: 0499
Cub Blue: 0685
Powder Black: 0637
1
2
