|ENGLISH| CADEX TRI USER MANUAL
4
D
TOP TUBE LENGTH (mm)
475
495
520
550
580
E
HEAD TUBE LENGTH (mm)
70
95
120
145
170
F
HEAD TUBE ANGLE
71.0°
73.0°
73.0°
73.0°
73.0°
G
FORK RAKE (mm)
40
40
40
40
40
H
TRAIL (mm)
76.1
63.3
63.3
63.3
63.3
I
WHEELBASE (mm)
968
976
1005
1039
1072
J
CHAIN STAY LENGTH (mm)
405
405
405
405
405
K
BOTTOM BRACKET DROP (mm)
80
80
77
74
74
L
ARMREST STACK (15D) (mm)
545 - 615
575 - 645
595 - 665
615 - 685
640 - 710
M
ARMREST REACH (15D) (mm)
340 - 430
355 - 445
375 - 465
400 - 490
425 - 515
FRAME STACK (mm)
483
513
534
555
579
FRAME REACH (mm)
390
405
426
452
478
N
HEIGHT (mm)
530 - 570
560 - 600
580 - 620
600 - 640
625 - 665
O
HANDLEBAR WIDTH (mm)
400
400
400
400
400
P
EXTENSION WIDTH (mm)
110 | 190
110 | 190
110 | 190
110 | 190
110 | 190
Q
ARMREST WIDTH (mm)
190 - 310
190 - 310
190 - 310
190 - 310
190 - 310
COMPATIBLE SIZE (mm)
700 x 28C
700 x 28C
700 x 28C
700 x 28C
700 x 28C
