Cadex TRI - Hydration System Operations

|ENGLISH| CADEX TRI USER MANUAL
11
5. HYDRATION SYSTEM REMOVAL & INSTALLATION
REMOVAL
1. Remove front aero cover by pulling outward with both hands (A)
2. Take out the bladder and disconnect the straw. Replace the bladder (B).
3. Use your index finger to unclip the straw while pressing the clip with your thumb (C)
4. Remove the straw by gently pulling through from the front side of the bike (D).
A
B
C
D
