|ENGLISH| CADEX TRI USER MANUAL
9
4. TOP TUBE STORAGE & TOOLKIT REMOVAL & INSTALLATION
NOTE:
Make sure all storage parts fit snugly to the frame and do not rattle.
TOP TUBE STORAGE REMOVAL
1. Hold the lower end firmly and push upwards (A).
2. Pivot the storage box upwards to remove. (B).
TOP TUBE STORAGE INSTALLATION
1. Insert and firmly push front latch into the frame recess (A).
2. Push storage box downward into the frame (B).
