3. Find the jacking location from the diagram above
and corresponding hoisting notches located in the
plastic molding.
The front location is (A) 8.5 inches (21 cm) from the
rear edge of the front wheel well, and the rear
location (B) is 3.5 inches (8.5 cm) from the front
edge of the rear wheel well.
The notches may also be labeled “JACK” with an
arrow pointing to the jacking location on the vehicle.
{CAUTION:
Getting under a vehicle when it is jacked up is
dangerous. If the vehicle slips off the jack you
could be badly injured or killed. Never get under
a vehicle when it is supported only by a jack.
{CAUTION:
Raising your vehicle with the jack improperly
positioned can damage the vehicle and even
make the vehicle fall. To help avoid personal
injury and vehicle damage, be sure to fit the
jack lift head into the proper location before
raising the vehicle.
4. Turn the jack handle counterclockwise to lower the
jack lift head until the jack fits under the vehicle.
5-81
