INSTRUMENT PANEL CLUSTER
1. Tachometer
2. Air Bag Readiness Light
3. Safety Belt Reminder Light
4. Security Light
5. Speedometer/Odometer
6. Engine Coolant Temperature Gage
7. Tire Pressure Light
8. ABS System Warning Light
9. Traction Control Warning Light
10. Driver Shift Control Display
11. Malfunction Indicator
(Check Engine) Lamp
12. Driver Information Center
13. Brake System Warning Light
14. Engine Coolant Temperature
Warning Light
15. Oil Pressure Light
16. Charging System Light
17. Engine Oil Pressure Gage
18. Lights On Reminder
19. Fuel Gage
1
2 3 4 5 6 7 8 9
11 1210
13
14 15 16 17 18 19
Note: The instrument cluster is designed to let you
know about many important aspects of your
vehicle’s operation. Some of the gages and
indicators may differ from the illustration presented.
The message center can provide critical information
to prevent damage to your vehicle. It is important
for you to read your Owner Manual and become
familiar with the information that is being relayed to
you by the lights, gages and indicators, particularly
the message center, as well as what action can be
taken to ensure your safety and to prevent damage.
