4. Remove the outlets tube from their positions by
pulling them straight up.
Place all loose parts in the flush bin with water and
clean with a brush.
5. After you have cleaned all parts, reassemble the
mixing tray in reverse order. Start by placing back the
outlet tubes to their mixer chambers.
6. Once the tubes are in position, slide back the cover all
the way down until the hooks "CLICKS" in at both front
and back side.
Check the tips of the outlet tubes so they are aligned
properly and not deformed in any way.
7. Depending how your machine is configured place
back the seals according to the pictures. Press them
down firmly, swipe your thumb all around the edges on
top of the seals to make sure they are in position.
Caution:
The milk seal can only be placed on the right side of
the mixer tray. There are ribs on the left side that
prevent the milk seal being placed there.
