At power-up, the letter b is displayed to indicate the phase of boot by the
microprocessor. Then, the reference of the firmware will be displayed to confirm the
correct function of the system implementation.
During power-up, the version of the software from Central appears a few seconds.
Once the complete boot sequence, the display turns off.
The plant is now operational and can be programmed: UHF channels, gain, etc.
IMPORTANT : To avoid any risk of deterioration of the central or other components
connected to the latter due to a too high output level, lower the gain to the minimum
settings: '30'.
2 / the frequency input UHF range programming
Press the 'OK' button for 5 seconds: the display shows the selection of the frequency
range of UHF inputs.
Ex :
Press 'OK': the display starts to Flash.
Press 'OK': the display starts to Flash.
With touch ⋀ and ⋁ do scroll through the different configurations of the LTE filter; press
'OK' to confirm your choice.
The LTE filter can be programmed to select the UHF frequency range
LtE.0 = 21... 69
LtE.4 = 21... 60
LtE.5 = 21... 48
3 / THE CONFIGURATION
Once the configuration of the LTE filter, you will enter the mode the configuration of
filters.
Press 'OK': the display starts to Flash.
With touch ⋀ and ⋁ do scroll through the different configurations of filters; press 'OK' to
confirm your choice.
Ex: Correlation table
Input UHF1 UHF2
Filtres group
10 0
6
