Modem / Logic
Addressing Serial
SETUP and COM Port
Interface EIA-232F DCE
Data Rate
Setup Port: 57,600 bps
COM Port: 110 – 57,600 bps (Default: 9.6 Kbps)
Display
5 Tri-color status LEDs
Power, Status, Rx, Tx, RD/TD
Connectors
Antenna Connector TNC Female (Tx/Rx), SMA Female (Rx) – Dual-Port and Full-Duplex models only
Serial Setup Port DE-9F
Serial COM Port DE-9F
User Interface I/O Right angle, 8 contacts (male)
Power – I/O I/O Right angle, 4 contacts (male) Power Plug
Diagnostics
Message Elements Temp, Voltage, Local/Remote RSSI, Forward Power, Reverse Power, Message Quality
Domestic and International Certifications
Model Number
Frequency
Range
FCC
IC (DOC)
European Union
EN 300 113
Australia /
New Zealand
140-5016-500 136 – 174 MHz NP4-5016-500 773B-5016500
140-5016-501 136 – 174 MHz NP4-5016-500 773B-5016500
140-5026-500 215 – 240 MHz NP4-5026-500 773B-5026500
140-5026-501
215 – 240 MHz
NP4-5026-500
773B-5026500
140-5046-300 406.1 – 470 MHz NP4-5046-300 773B-5046300
140-5046-301 406.1 – 470 MHz NP4-5046-300 773B-5046300
140-5046-500 450 – 512 MHz NP4-5046-300 773B-5046300
140-5046-501 450 – 512 MHz NP4-5046-300 773B-5046300
140-5096-500 928 – 960 MHz NP4-5096-500 773B-5096500
140-5096-501 928 – 960 MHz NP4-5096-500 773B-5096500
UL Certification
All models UL approved when powered with a listed Class 2 source.
This device is suitable for use in Class I, Division 2, Group A, B, C and D or non-hazardous
locations only.
Guardian™ Serial Modem or Analog Radio for Licensed Spectrum PN 001-5006-000 Rev. 3 | Page 59
