2.9 SPECIFICATIONS
These specifications are subject to change without notice. RF specifications are measured per TIA/EIA-603 with a
psophometric baseband filter.
General
VHF
UHF
900 MHz
Frequency
132-174 MHz
380-400 MHz*, 403-512 MHz,
406.1-476 MHz Dual Band
928-960 MHz
Channels
Multi-channel capability under system PLC control
Channel Bandwidth
6.25, 12.5 or 25 kHz models
Operating Temperature
-30° to + 60° C
Supply Voltage
10 - 16 VDC maximum (nominal 13.3) Fuse protected against reverse voltage
(internal surface mount 3A fuse: not field replaceable)
RX Current Drain at 13.3 VDC
<220 mA (with a terminal connected to Integra-TR COM port)
TX Current Drain at 13.3 VDC
<2.6 A
Power Saving Mode Current Drain
<20 mA
Cold Start
1
4 sec (typical)
Warm Start Rx
2
45 to 60 ms (depending on radio model and temperature)
Warm Start Tx
3
55 to 70 ms (depending on radio model and temperature)
Tx Turn On Time
4
15 ms (typical)
RX/TX Bandwidth (without tuning)
18 MHz (132-150)
24 MHz (150-174)
16 MHz except
20 MHz (380-400, 450-470)
34 MHz (406.1-440 Dual)
36 MHz (440-476 Dual)
32 MHz
*380 to 400 MHz frequency band is not FCC or IC type approved
+
Includes 102 cm power cable
Receiver
VHF
UHF
900 MHz
Sensitivity
0.35 µV for 12 dB SINAD
Selectivity (25 kHz)
>70 dB minimum
>65 dB Minimum UHF Dual Band
> 65 dB minimum
Selectivity (12.5 kHz)
>60 dB minimum
>55 dB Minimum UHF Dual Band
>60 dB minimum
Intermodulation
>70 dB minimum
> 70 dB minimum
Spurious Rejection
>70 dB minimum
>70 dB minimum
FM Hum and Noise
<-45 dB max (25 kHz)
<-40 dB max (25 kHz)
Conducted Spurious
< -57 dBm
