4 CONFIGURABLE PARAMETERS
4.1 PARAMETER OVERVIEW
The parameters used to configure the Integra-TR units are described in the Field Programming Software help file. Section 4
summarizes the Integra-TR parameter settings and their variations when used within a network.
Table 11 - Normal Factory Settings (Units)
Fields
Integra-TR with other Integra-TR
Integra-T / TR
Integra-T
Network Settings
Compatibility Mode
Integra-TR
Integra-T / TR
(N/A)
Tx/Rx Mode
Both Tx and Rx
(N/A)
Extended Preamble (ms)
5 mS
0 mS
0 mS
Network Speed
19200 Full Channel
9600 Half Channel
2400 Quarter Channel
9600 Full Channel
Tx Online Diagnostics
Yes
Unit Type
Master
Data Delivery
All
Suspend Period (ms)
0
Activity Time-out (sec)
5
Sleep Mode
Disable (N/A)
COM Port
Device Baud
19200
9600
Data fwd timer
Normal
Parity
8 bit, no parity, 1 stop bit
Break
Ignore break
Xmit Control
DOX
DCD Control
Switched
External I/O Connector
I/O 1
Input or Fan Control (units with cooling fan option) Digital Output
(units not equipped with cooling fan option when Modem Board
Rev is 0 or 1)
Input
I/O 2
Input Digital Output to control open-collector transistor (when Modem Board Rev is 0 or
1)
Frequency
Transmit
User choice
Receive
User choice
Adjustments
Carrier Sense (-dBm)
105 (116 for quarter-channel)
110
Tx Time Out
30 sec ON
Disable Tx w/ Carrier Present
Disabled (OFF)
Power Out
255 (indicates 5 Watts nominal)
Transceiver Type
Transceiver
Refer to help files (See section 3.5) for descriptions of the above fields.
