Integra-TR User Manual Page | 19
Interface
Two outputs, requires external pull-up to 2 to 10 Vdc. Set via Offline Diagnostics
Display
4 Bi-color status LEDs
RUN/PWR/ CS/SYN, RX/TX, RD/TD
Connectors
RF
SMA Female
COM
DE-9F
SETUP/DIAG
DE-9F
Power - I/O
Snap & Lock 4-Pin DC Power Jack
Diagnostics
Online
Short ID, temperature, B+ voltage, local RSSI, remote RSSI, fwd and rev power, Rx
Quality
Offline
As for Online plus: Demodulated Signal Voltage, Analog Input Levels, Digital
Outputs
Certifications
FCC (6.25 kHz)
FCC (12.5 & 25 kHz)
IC (DOC)
VHF
NP4MCUA5Q
6K00F1D
EOTMCUA5R
9K30F1D, 15K3F1D
773195562A
9K30F1D, 15K3F1D
UHF
NP4MCUB5Q
6K00F1D
EOTMCUB5R
9K30F1D, 15K3F1D
773195561A
9K30F1D, 15K3F1D
UHF Dual Band
NP44048350
9K30F1D, 15K3F1D
773B-4048350
9K30F1D, 15K3F1D
900 MHz
NA
EOTMCUC5R
9K30F1D, 15K3F1D
7731955611A
9K30F1D, 15K3F1D
