TECHNICAL DATA SHEET FOR
MODEL BEF- 5 BEAM END FITTINGS
Top rigging component configuration will depend on the crane hook size and type of top rigging used.
These top rigging components will need to be sized to a rated capacity equal to or greater than the
capacity of the Grade 80 alloy chain, 6X19, or 6X37 Extra Improved Plow with Independent Wire Rope
Core wire sling that is used. If there are questions on proper sizing of rigging components, contact The
Caldwell Group or your rigging supplier.
TABLE 3: Shows the recommended sizes and capacity for the hardware tabulated by spreader beam
capacity in tons. Hardware must be rated at least the minimum capacity defined in TABLE 3. for either
the Top Rigging or Bottom Rigging based on the tabulated spreader beam capacity.
Caldwell Model BEF- 5 Spreader System Rigging Hardware Selection Table
Top Rigging Bottom Rigging
Spreader Cap.
(in Tons)
Crosby Shackle
Description
Part Number
Crosby Shackle
Description
Part Number
Crosby Hook
Description
Part Number
4.5 4 ¾T BTAS S-2130 3 ¼T BTAS S-2130 3T Swivel Hook 322C
5 4 ¾T BTAS S-2130 3 ¼T BTAS S-2130 3T Swivel Hook 322C
5.5 4 ¾T BTAS S-2130 3 ¼T BTAS S-2130 3T Swivel Hook 322C
6 4 ¾T BTAS S-2130 3 ¼T BTAS S-2130 3T Swivel Hook 322C
6.5 6 ½T BTAS S-2130 3 ¼T BTAS S-2130 4 ½T Swivel Hook 322A
7 6 ½T BTAS S-2130 4 ¾T BTAS S-2130 4 ½T Swivel Hook 322A
7.5 6 ½T BTAS S-2130 4 ¾T BTAS S-2130 4 ½T Swivel Hook 322A
8 6 ½T BTAS S-2130 4 ¾T BTAS S-2130 4 ½T Swivel Hook 322A
8.5 6 ½T BTAS S-2130 4 ¾T BTAS S-2130 4 ½T Swivel Hook 322A
9 6 ½T BTAS S-2130 4 ¾T BTAS S-2130 4 ½T Swivel Hook 322A
9.5 8 ½T BTAS S-2130 4 ¾T BTAS S-2130 5T Swivel Hook 322C
10 8 ½T BTAS S-2130 6 ½T BTAS S-2130 5T Swivel Hook 322C
10.5 8 ½T BTAS S-2130 6 ½T BTAS S-2130 7T Swivel Hook 322A
11 8 ½T BTAS S-2130 6 ½T BTAS S-2130 7T Swivel Hook 322A
12
9 ½T BTAS S-2130 6 ½T BTAS S-2130 7T Swivel Hook 322A
12.5
9 ½T BTAS S-2130 6 ½T BTAS S-2130 7T Swivel Hook 322A
13
9 ½T BTAS S-2130 6 ½T BTAS S-2130 7T Swivel Hook 322A
13.5
12 T BTAS S-2130 8 ½T BTAS S-2130 7T Swivel Hook 322A
14
12 T BTAS S-2130 8 ½T BTAS S-2130 7T Swivel Hook 322A
14.5
12 T BTAS S-2130 8 ½T BTAS S-2130 7 ½T Swivel Hook 322C
15
12 T BTAS S-2130 8 ½T BTAS S-2130 7 ½T Swivel Hook 322C
15.5
12 T BTAS S-2130 8 ½T BTAS S-2130 10T Swivel Hook 322C
16
12 T BTAS S-2130 8 ½T BTAS S-2130 10T Swivel Hook 322C
16.5
12 T BTAS S-2130 8 ½T BTAS S-2130 10T Swivel Hook 322C
17
12 T BTAS S-2130 8 ½T BTAS S-2130 10T Swivel Hook 322C
* BTAS indicates Bolt Type Anchor Shackle
Table 3.
