Calorex AW631 - Page 14

Page 12
ELECTRIC BOX ACCESS
REMOVE THE 6 SCREWS FROM
TOP COVER AND LIFT OFF
N L
WATER PRESSURE
SWITCH
SOFT START
KIT
FAN L
FAN N
ENERGY MANAGEMENT
CONTROLLER
WATER FLOW
SWITCH
INTERLOCKS
REVERSING
VALVE
SWITCH
REVERSING
VALVE
'Y' VRSN
ONLY
2 4 6 1 3 5
REMOVE THE 6 SCREWS FROM
SERVICE PANEL AND LIFT OFF
MAINS IN
BOTH
ENDS
1 PHASE 230V ~ 1N 50Hz
N L
WATER PRESSURE
SWITCH
SOFT START
KIT
FAN L
FAN N
ENERGY MANAGEMENT
CONTROLLER
WATER FLOW
INTERLOCKS
SWITCH
REVERSING
VALVE
'Y' VRSN
ONLY
3 PHASE 400V ~ 3N 50Hz
N L
WATER PRESSURE
SWITCH
SOFT START
KIT
FAN L
FAN N
ENERGY MANAGEMENT
CONTROLLER
WATER FLOW
SWITCH
INTERLOCKS
L L
1 32
REVERSING
VALVE
'Y' VRSN
ONLY
LOCATION OF ELECTRICAL SUPPLY CONNECTIONS IN 31 RANGE HEAT PUMP
FIGURE 5
