HEAT PUMPS FOR OUTDOOR POOLS
REVERSE CYCLE DEFROST (ALY, BLY)
MODEL Units AW631 AW831 AW1231 AW1531
HEAT TO POOL WATER
AMBIENT 10°C, WATER 24°C :- kWhr 7.2 9.9 12.4 17.7
ELECTRICAL
ELECTRICAL SUPPLY 1 PHASE
ELECTRICAL SUPPLY 3 PHASE
TOTAL POWER CONSUMED:-
AMBIENT 10°C, WATER 24°C :- kWhr 1.8 2.3 3.1 4.2
AMBIENT 20°C, WATER 24°C :- kWhr 2.0 2.5 3.3 4.3
MIN SUPPLY CAPACITY (Max F.L.A.) 1 ph N:- amps 14.3 17.4 19.0 N/A
MIN SUPPLY CAPACITY (Max F.L.A.) 3 ph N:- amps 6.0 6.2 8.0 13.0
MAX' SUPPLY FUSE 1 ph N:- amps 20.0 25.0 30.0 N/A
MAX' SUPPLY FUSE 3 ph N:- amps 10.0 10.0 15.0 18.0
WATER FLOWS ETC
POOL WATER FLOW RATE:- litres/min 115 115 160 160
POOL WATER PRESSURE DROP (@ Rated Flow):- metres hd 1.0 1.0 2.0 2.0
MAX WORKING PRESSURE POOL WATER:- bar 3.5 3.5 3.5 3.5
POOL WATER CONNECTIONS:- inches 1 1/2" BSPM 1 1/2" BSPM 1 1/2" BSPM 1 1/2" BSPM
CONDENSATE DRAIN CONNECTIONS:- inches 3/4" BSPM STUD 3/4" BSPM STUD 3/4" BSPM STUD 3/4" BSPM STUD
COMPRESSOR
NOMINAL POWER CONSUMED:- kWhr 1.8 2.14 2.6 3.8
LRA.- 1 ph N:- amps 66 63 100 N/A
RLA:- 1 ph N:- amps 11.4 14 16.6 N/A
SOFT START AMPS 1 ph N:- amps 29 31 35 N/A
LRA:- 3ph N:- amps 32 30 48 48
RLA: -3 ph N:- amps 4 4.65 7.3 10
SOFT START AMPS 3 ph N:- amps 14 14 17 25
MAlN FAN
AIR FLOW (Anemometer @ air on grille. Wet evaporator):- m³/hr 1800 2700 3000 4700
MAX EXTERNAL STATIC PRESSURE :- mm Wg0000
FLA:- 1 ph N:- am ps 0.7 0.7 0.97 2
GENERAL DATA
HERMETIC SYSTEM
GAS CHARGE R407c kg 2.31 3.0 4.5 4.5
PHYSICAL DIMENSIONS
WIDTH (Un-packed):- mm 1076 1076 1076 1200
DEPTH (Un-packed):- mm 485 485 485 485
HEIGHT (Un-packed):- mm 1255 1255 1355 1355
WEIGHT (Un-packed) :- kg 133 142 157 170
230V/~1N/50Hz
400V/~3N/50Hz
For Accurate Application Sizing Consult CALOREX Heat Pumps Ltd.
NOTES:
1) Weight and dimensions nett
2) Performance design Iimitations
Ambient = -15°C min, 35°C max
Water = 10°C min, 40°C max
3) Pool water to have correct balance, pH 7.4 ± 0.4 Free Chlorine 1.0 - 3.0 ppm
4) Allow 500mm clearance to service panels
5) Calorex reserve the right to change or modify models without prior notice.
6) R407c Global Warming Potential (GWP) 1700.
1mm WG = 9.8 Pa
1m hd = 1.4 psi
1L/min = 0.22 gall/min
