Cambium Networks PTP 820C Quick Start Guide

PTP 820C Quick Start Guide
Page 12
To connect the PoE Injector cables
 The total length of the cable between the PTP 820C port and the
Switch/Router the device is connected to should not exceed 100m/328ft.
This length includes the connection between the PTP 820C and the PoE
Injector (
X1 + X2
≤ 100m/328ft in the figure to the right).
 The length of the cable connecting the customer equipment to the PoE
injector should not be longer than 10m (according to ANSI/TIA-568
standard).
PTP 820C
X2
DC
X1
CSR
