S-TM7-02-18
S400-S3200 REV. F
S-SERIES
DIRECT GAS-FIRED
INDUSTRIAL BLOW-THRU
®
SPACE HEATER
TECHNICAL MANUAL
mWARNING:
Improper installation, adjustment, alteration, service or maintenance can cause property dam-
age, injury or death. Read the installation, operating, and maintenance instructions thoroughly
before installing or servicing this equipment.
FOR YOUR SAFETY
The use and storage of gasoline or other flammable vapors and liquids in open containers in
the vicinity of this appliance is hazardous.
FOR YOUR SAFETY
If you smell gas:
1. Open windows.
2. Don’t touch electrical switches.
3. Extinguish any open flame.
4. Immediately call your gas supplier.
®
90.1
ASHRAE
ASHRAE
COMPLIANT
COMPLIANT
Made in the USA
®

Table of Contents

Questions and Answers

  • C
    Colleen HodgeAug 5, 2025
    How to troubleshoot no blower operation in Cambridge Engineering Heater?
    • H
      hollandjefferyAug 5, 2025
      If the Cambridge Engineering Heater blower isn't running, first ensure the unit isn't in reset by turning it OFF and then ON again. Check that the heater disconnect is ON. Verify the mode selector switch on the RCS is in the correct mode and adjust the operating thermostat if needed. Make sure the blower service switch is in the REMOTE position. Examine the control and Class 2 transformers, checking the disconnect, supply fusing, and supply voltage. Also, inspect the multi-functional PC board, checking the voltage in the RCS. Other potential causes include the damper motor (adjust damper stroke), motor protection/starter/motor (check primary power source or replace starter), blower (replace bearings), or belts (tighten belts).
  • W
    williamjamesAug 9, 2025
    What to do if Cambridge Engineering Heater modulating valve does not modulate and runs on continuous high fire?
    • J
      Jason MartinezAug 9, 2025
      If the Cambridge Engineering Heater's modulating valve is stuck on continuous high fire, try reinstalling the wire on the amplifier (A1014, A1044, or AD1014). You might also need to clean the Discharge Air Temperature Sampling Tube for the discharge temperature sensor (TS114J or TS144). For Series 44 models, replace the space temperature selector if resistance exceeds specified values (7,000 ? for T244; 5,500 ? for TS244; or 2,250 ? for TD244). For Series 14, recalibrate or replace the space thermostat. If using a remote heat adjust (TD114 or CEI 4175-0-960), replace it if resistance between terminals 1 and 3 is less than 6,000 ?.
  • E
    Eduardo SandersAug 14, 2025
    What to do if Cambridge Engineering Heater blower runs, but there is no heat and flame safety relay locks out?
    • D
      Deanna LeachAug 14, 2025
      If the blower runs but the Cambridge Engineering Heater doesn't heat and the flame safety relay locks out, start by checking the igniter current. Also, check the gas supply for low or no gas pressure using the high or low gas pressure switches. Inspect the gas valve, verifying the FSR output to the R1 relay during ignition. Finally, adjust the minimum fire on the modulating valve.
  • B
    Benjamin MortonAug 17, 2025
    Why Cambridge Engineering S1200 Heater blower runs, unit heats, but will not cycle off?
    • R
      Ruben JonesAug 18, 2025
      If the Cambridge Engineering Heater blower runs, the unit heats, but it won't cycle off, first check the thermistor wiring and consider replacing the thermistor for the operating thermostat. Ensure the burner service switch is in the REMOTE position. Inspect the auxiliary circuit wiring and contacts. Consider reviewing the control system's operational characteristics to ensure proper understanding.
  • M
    Michelle SmithAug 22, 2025
    What to do if Cambridge Engineering S1200 modulating valve does not modulate and runs on continuous low fire?
    • C
      carpentermatthewAug 22, 2025
      If the Cambridge Engineering Heater's modulating valve is stuck on continuous low fire, start by checking for a short in the modulating valve coil using the Class 2 transformer. If the valve coil resistance is less than 40 ? or greater than 85 ?, replace it. With the wire removed from terminal 3 of the amplifier, replace the amplifier if the valve voltage doesn't exceed 18 Volts DC. Replace the discharge temperature sensor (TS114J or TS144) if the resistance at terminals 1 and 2 on TS114J is less than 8,000 ?. Also, replace the space temperature selector (T244 or TS244/TD244) if the resistance is less than 5,000 ? for the T244, 3,500 ? for the S244, or 1,950 ? for the TD244.
  • D
    Derek SandersAug 27, 2025
    What to do if Cambridge Engineering S1200 blower runs, but there is no heat and flame safety relay doesn’t lock out?
    • G
      Gregory MillerAug 27, 2025
      If the Cambridge Engineering Heater blower is running but there's no heat and the flame safety relay isn't locking out, first, ensure the mode selector switch is in the HEAT position. Then, check that the burner service switch is in the REMOTE position. After that, check the voltage in the RCS using the multi-functional PC board. You may also need to reverse the motor direction on the airflow switch. Finally, check the wiring of the flame safeguard relay.
  • J
    James SimsAug 31, 2025
    How to fix erratic or pulsating flame in Cambridge Engineering Heater?
    • S
      Sara GarciaAug 31, 2025
      To address an erratic or pulsating flame in your Cambridge Engineering Heater, start by enlarging the vent piping size or reducing the vent piping length for the high-pressure regulator. Then, adjust the sensitivity control dial on the amplifier counter-clockwise. For the space temperature selector (T244 or TS244/TD244) and remote heat adjust (TD114 or CEI 4175-0-960), use shielded, twisted pair wiring.

Summary

HAZARD SUMMARY

Hazard Identification and Warnings

Explains the meaning of WARNING, CAUTION, and other safety alerts in the manual.

INSTALLATION INSTRUCTIONS

Uncrating and Mounting Location

Roof Top Mounting

Details the installation process for roof-mounted configurations, including curb/stand/rail.

Thru Wall Mounting

Explains the procedures for mounting the unit through a wall, including hanging rods.

Under Roof Mounting

Outlines the installation steps for units mounted under the roof structure using a curb.

Vertical Mounting Options

Gas Piping and Electrical Wiring

Provides essential information and instructions for gas piping and electrical wiring connections.

START-UP INSTRUCTIONS

Start-Up Procedure Checklist

Lists the essential steps and checks for a successful and safe initial equipment start-up.

CALIBRATION PROCEDURES

Control System Calibration

Explains calibration steps for EDL, EDSM/TP, and EDR control systems.

OPERATING INSTRUCTIONS

Operating Sequence

Electronic Thermostat Operation

TSS Controller Operation

Setting Schedules and Temperatures

MAINTENANCE INSTRUCTIONS

Burner and Gas Valve Maintenance

TROUBLESHOOTING INSTRUCTIONS

Troubleshooting Guide by Symptom

A comprehensive guide to diagnose and resolve various operational issues based on symptoms.

Damper Motor Adjustment

INDIVIDUAL COMPONENT DESCRIPTIONS

Gas Control Systems and Components
