CAMDEN CX-12 PLUS User Manual

Page 7 of 15
CX-12 PLUS DOOR INTERFACE RELAY INSTALLATION INSTRUCTIONS
FILENAME: CX-12PLUS-Diagram2a.ai
DRAWING No: DRG-CX-12PLUS-02
CX-12PLUS Application Diagram (with Maintained Lock Output)
SCALE: NONE
DRAWN BY: DGW REVISED: 1/28/2020DATE: 11/16/09
5502 Timberlea Blvd.
Mississauga, Ontario
L4W 2T7
12/24 V
AC/DC
Power
Electric Strike
(If Mag lock used, wire to Terminals 4 & 5)
Exterior Switch (in circuit only while Lock Relay is active)
Interior Switch (always unlocks and opens door)
Access Control / Time Clock
(sends a powered & maintained signal
to keep door unlocked for desired time)
Wire MOV
(supplied)
directly to strike
or magnet
Power
for Strike
DRY2WET2DRY1WET1POWER
NO
NO
NC
NC
COM
COM
Relay2Relay1
CX-12 PLUS
CAMDEN DOOR CONTROLS
Door Operator
1 52 3 4 6 7 8 9 10 11 12 13 14 15 16
RL1 RL2
DOR
RL1
DOO
RL2
DOR
RL2
OFF / ON
1 2 3
+
-
MOV
